415V Automatic Liquid Filling Machine

415V Automatic Liquid Filling Machine

  • High Light

    415V Automatic Liquid Filling Machine


    1650mm Automatic Liquid Filling Machine


    415V liquid bottle filling machine

  • Type
    Filling Machine
  • Automatic Grade
    Full Auto
  • Driven Type
  • Voltage
    220V / 380V / 415V
  • Dimension(L*W*H)
  • Weight
  • Name
    Automatic Disinfection Hand Sanitizer Filling Sealing Machine
  • Filling Type
    Piston Filling Machine
  • Certification
  • Machine Type
    Shrink Labeling
  • Condition
  • Key Selling Points
    Easy To Operate
  • Packaging Type
    Plastic Bottle Glass Bottle
  • Main Function
    Disinfection Liquid Bottle Filling Sealing
  • Application
  • Power
  • Gas Consumption
  • Working Air Pressure
  • Material
    Stainless Steel
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
  • Price
  • Packaging Details
    wood case
  • Delivery Time
    20 working days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10 sets per month

415V Automatic Liquid Filling Machine

Hand sanitizer liquid filling machine ethanol disinfectants filling machine disinfection liquid filling machine

Product Description:

1.Qty of filling head: 4-20 head (depending on the designing).
2.Filling capacity: 50ML-5000ML (Compatible filling capacity tolerance for a single machine is one times. To be determined by
customer requirements).
3.Filling method: Equal-liquid level self flowing type.
4.Filling speed: 6~8 bottles/min. head (500ml bottle).
5.Filling accuracy: ±1%.
6.Program control: PLC + touch screen.
7.Main materials: #304 stainless steel, PVC used in food industry.
8.Air pressure: 0.6-0.8Mpa.
9.Conveyer belt: Stainless steel chain belt of 82mm in width. Speed: 0-15m/min. Distance away from the ground: 750mm±25mm.
10.Conveyor motor: 370W frequency conversion speed regulation motor.
11.Power: 1KW/220V single phase.
12.Capacity of material tank: 200L (with liquid level switch).

13.Protective device: Outage alarm on shortage of liquid in the reservoirtank.

Features:Filling volume, filling speed can be adjustable, bottom close positive shutoff nozzles ensure drip free operations; The diameter of the filling nozzle optional within 3mm-12mm;
Piston type filling, can be operated by foot pedal or by automatic timer, could transfer between semi-automatc and automaitc;
Use silica gel O-ring(cam bear 200 Celsius degree), comply with the food safety; Can optional silica gel ring or rubber sealing ring, rubber sealing ring used for anti-corrosion produce;
One head with one cylinders, filling head can optional single head, two head;
Can optional the machine model: 10-150ml 20-300ml 50-600ml 120-1200ml 260-2600ml 500-5000ml;
Use for filling liquidity is good material, such as water, cooking oil, juice, milk, wine, liquid medicine, liquid detergent etc;
Adopt Airtac pneumatic components, full pneumatic drive does not need electrical power, need to contact to the air compressor; safety explosion-proof type, simple operation, high filling accuracy;

Product name
Disinfectant Filling Machine
Filling volume
5-150 30-500 60-1000g
Filling Speed
20-40 B/min
Stainless steel 304 & 316L
Pharmaceutical, strong corrosive liquid (such as color bleach, 84 liquid, toilet cleaning liquid, bleach liquid,daily chemical, pesticide)
Piston filling
Material hopper
Suitable bottle size

415V Automatic Liquid Filling Machine 0



415V Automatic Liquid Filling Machine 1



415V Automatic Liquid Filling Machine 2

415V Automatic Liquid Filling Machine 3

415V Automatic Liquid Filling Machine 4

415V Automatic Liquid Filling Machine 5

Zhangjiagang City Bievo Machinery Co., Ltd. is located in a national level development zone - Zhangjiagang Economic And Technology Development Zone, covering area more than 8,000 square meters.We enjoy convenient transportation with Shanghai Hongqiao International Airport and Shanghai Pudong International Airport on hand.Which accumulated a great number of China's top technologists in the liquid beverage industry.We have complete system from designing, manufacturing, installation, training to after service.Our main product water production line, carbonated beverage production line . Fruit juice and milk production line ,3 to 5 gallons production line, daily chemical production line and so on.Plat and tube UHT device, CIP system.All the products are sold well.We devote ourselves to the development, research and production of liquid food and beverage filling and packing industry .

415V Automatic Liquid Filling Machine 6

415V Automatic Liquid Filling Machine 7

Q1: How to find a Packing machine suitable for my product?
Tell us about your product details and packing requirements.
1. What kind of product you would like to pack?
2. The bag/sachet/pouch size of you need for the product packing ( the length, width).
3. The weigh of each pack you need.
4. You requirement for the machines and the bag style.

Q2: Is engineer available to serve oversea?
Yes, but the travel fee is responsible by you.
In order to save your cost, we will send you a video of full details machine installation and assist you till the end.

Q3. How can we make sure about the machine quality after placking the order?
Before delivery, we will send you the pictures and videos for you to check the machine quality.
And also you can arrange for quality checking by yourself or by your contacts in China.

Q4. We are afraid you won't send us the machine after we send you the money?
We have our business license and certificate. And it is available for us to use alibaba trade assurance service,guarantee your
money, and guarantee your machine's on-time delivery and machine quality.

Q5. Can you explain me the whole transaction process ?
1.Sign the Contact
2.Arrange 30% deposit to our factory
3.Factory arrange production
4.Testing & detecting the machine before shipping
5.Inspected by customer or third agency through online or site test.
6.Arrange the balance payment before shipment.

Q6: Will you provides the delivery service?
A: Yes. Please inform us of your final destination, we will check with our shipping agent to quote the shipping cost for your
reference before delivery.

415V Automatic Liquid Filling Machine 8

<1>Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.

Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

<3>Quality guarantee
We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.
