Product Details:

Place of Origin: China,Jiangsu
Brand Name: BIEVO
Certification: CE
Model Number: CGZ32-32-10

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: 45000dollers/set
Packaging Details: wood case
Delivery Time: 30working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 sets per month
Get Best Price Contact Now

Detail Information

Model: CGZ32-32-10 Machinery Capacity: 10000BPH
Product Name: Pure Water Making Machine Material: Stainless Steel
Voltage: 380V/220V Dimension(L*W*H): 2100*1800*2250 Mm
Weight: 3500KG Filling Material: Drinking Water
Bottle Shape: Customized Key Selling Points: High Precision
Bottle Size: 200ml-2000ml Usage: Liquid Filling
Control System: PLC+Touch Screen Filling Type: Gravity Filling
Application: Bottle Water Plant Packaging Material: PE Film/carton Packing
Driven Type: Electric Filling Accuracy: 0.1%
Product: Bottle Drinking Water
High Light:

10000bph Water Bottles Filling Machine

,

CGZ32-32-10 Water Bottles Filling Machine

,

CGZ32-32-10 monoblock liquid filling machine

Product Description

10000BPH stainless steel mineral water production line/plastic bottle water filling machine/pure water making machine



Inroduction of  Water Production Line:



This Automatic 3-in-1 Wash-filling-capping Water Filling Machine is used to produce bottled mineral water, purified water, flavored water, alcoholic beverage and other non-gas Liquid. This Machine can be applied to all kinds of plastic products such as PET, PE. Bottles size varies from 250ml-2500ml meanwhile few changeover is needed. This series of filling machine capacity varies from 1000BPH to 32000BPH.

Our water filling machine is designed for the bottle water factory. It features low water and low electricity consumption, small space occupation as well as easy operation. At the same time It improves the sanitary conditions and simplifies the maintenance compared with the last generation water filling machine. it can perfectly complete the function of automatic washing, filling and capping, which has been aproved by our clients as technical matured and quality product.



Main Features Of Small Bottle Drinking Water Filling Machine

1. Air conveyor system is adopted in bottle entry section and belt conveyor system is adopted in bottle exit section, the two conveyor system speed can be adjusted to work in synchronization with transducer of the main machine to make the operations of moving bottle steadily and reliably,

2. It adopt hanging type conveying-bottle structure, The bottle neck is cramped and bottles are suspended during the operation process, this avoid many malfunctions caused by thinner bottle body and different height of bottles, the design also reduce the required number of changeable parts for changing between various bottle, make bottle change more convenient and with high efficiency,

3. Japanese and Italy technology is employed by balanced pressure filling, with liquid tank and bottle inside pressure balanced during filling, the filling is faster and liquid level is accurately controlled, and avoid leakage and dropping,

4. Spring cramps are used in the bottle washing process, the empty bottle can be turned over 180degree along the conveying rail, there are two times of internal and external washing to guarantee high efficiency for washing

5. The magnetic torque is used for screw capping, the force of cap grabing, and screw capping can be adjusted steplessly, the force of the screw capping can also be fixed to avoid cap damaged and make sure reliable capping

6. The horizontal rotary pneumatic cap sorting device is used to avoid the damage to the surface of the caps, and when there is a shortage of caps in the cap storage tank, alarm signal will be generated and the caps will be fed automatically

7. The whole machine is controlled by PLC program with touch screen as the human-machine interface,The liquid level in the storage tank is automatically controlled, the filling and capping will automatically stop when there is no bottle, when the bottles are cramped wrongly or when caps not available, the machine will stop automatically,

8. Use Mitsubishi frequency changing technology to adjust the operation speed steplessly,the production capacity will be displayed digitally and easy for adjusting,

9. All parts that have direct contact with water are made in SUS304 stainless steel to reach the requirements of Food sanitation

10. Main components of the machine is adopting imported brands,PLC and touch screen from Mitsubishi, electronics from Schneider and Omron, pneumatic parts from Airtac or Festo,Main motor from Siemens, and Transducer from Mitsubishi, to guarantee heavy duty machine

Stainless Steel 220V 10000bph Water Bottles Filling Machine 0on.

Model CGZ8-8-3 CGZ12-12-6 CGZ18-18-6 CGZ24-24-8 CGF32-32-8 CGF40-40-12
Capacity 3000BPH 4000BPH 8000BPH 12000BPH 15000BPH 20000BPH
Applicable bottle type Bottle diameter:50-100mm; height:150-320mm;Volume:330-1500ml
Applicable bottle shape Plastic Screw cap
Gas pressure 0.6 0.6 0.6 0.6 0.6 0.6
Motor power 2.3 3.1 3.5 3.8 3.8 4.2
Pressure 2-3kg/cm2
Machine size 2.2*1.8*2.3 m 2.45*1.65*2.1m 2.6*1.8*2.1m 3*2.2*2.4m 4*2.2*2.4m 4.1*2.782.6m
Weight 1800kg 2000kg 2500kg 4200kg 4800kg 5000kg





























Stainless Steel 220V 10000bph Water Bottles Filling Machine 1

Model CGZ32-32-10
Volume of PET bottle 0.25L-2L
Diameter of bottle 50-100mm
Height of bottle 170-320mm
Filling pressure Less than 0.15Mpa
Filling precision Less than 2%-3%
Pressure of washing 0.2Mpa
Washing water consumption 600kg/h
Gas consumption 0.4m3/min
Power of main motor 5.6KW
Dimension 2200*1800*2250mm

Machine's Details:

Stainless Steel 220V 10000bph Water Bottles Filling Machine 2

Washing Part Of Small Bottle Mineral Water Filling Machine
Stainless Steel 220V 10000bph Water Bottles Filling Machine 3
Function : washing bottle inside and outside dust .
- Into bottle way is air conveyor direct connection with bottle dial.
- All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean.
- 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.
- 304/316 stainless steel washing pump make the machine more durable.
Filling Part Of Small Bottle Mineral Water Filling Machine
Stainless Steel 220V 10000bph Water Bottles Filling Machine 4
Fucntion : filling wine into bottle .
- 304/316 Stainless steel high precision filling nozzle
- Filling volume adjustable in fine rank, same liquid level after filling
- All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
- 304/316 stainless steel filling pump
- Efficient spray nozzle rinse thoroughly and save water for flushing
Capping Part
Stainless Steel 220V 10000bph Water Bottles Filling Machine 5
Function : put caps on bottle .
- Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping.
- All 304/316 stainless steel construction
- No bottle no capping
- Automatic stop when lack of bottle
- Capping effect is stable and reliable, Defective rate ≤0.2%

Bottled water plant machinery:
1. (Making bottle) Full automatic bottle blow machine or Semi automatic bottle blow machine
2. (Water Filtration) RO water purification machine / UF mineral water filtration machine.
3. (Filling water into bottle) Bottle washing filling and capping machine.
4. (Labeling bottle water) Shrink sleeve labeling machine or Sticker labeling machine.
5. (Printing the date on the bottle water) Date printing machine.
6. (package the bottle water) Full automatic shrink wrapping packing machine or Semi automatic shrink wrapping packing machine / Carton box packing machine.

Electrical Appliances Brand :

Electrical Appliances Brand
 Stainless Steel 220V 10000bph Water Bottles Filling Machine 6  Stainless Steel 220V 10000bph Water Bottles Filling Machine 7  Stainless Steel 220V 10000bph Water Bottles Filling Machine 8  Stainless Steel 220V 10000bph Water Bottles Filling Machine 9
CNP Water Pump Siemens/ABB Main Motor Siemens/Mitsubishi PLC Siemens Inveter
 Stainless Steel 220V 10000bph Water Bottles Filling Machine 10  Stainless Steel 220V 10000bph Water Bottles Filling Machine 11  Stainless Steel 220V 10000bph Water Bottles Filling Machine 12  Stainless Steel 220V 10000bph Water Bottles Filling Machine 13
Siemens Touch Screen Schneider Circuit Breaker Schneider Contactor Omron Relay
 Stainless Steel 220V 10000bph Water Bottles Filling Machine 14  Stainless Steel 220V 10000bph Water Bottles Filling Machine 15  Stainless Steel 220V 10000bph Water Bottles Filling Machine 16  Stainless Steel 220V 10000bph Water Bottles Filling Machine 17
Omron Sensor SMC Solenoid Valve SMC Cylinder SMC Air Filter



Stainless Steel 220V 10000bph Water Bottles Filling Machine 18

Stainless Steel 220V 10000bph Water Bottles Filling Machine 19

Stainless Steel 220V 10000bph Water Bottles Filling Machine 20

Zhangjiagang City Bievo Machinery Co., Ltd. is located in a national level development zone - Zhangjiagang Economic And Technology Development Zone, covering area more than 8,000 square meters.We enjoy convenient transportation with Shanghai Hongqiao International Airport and Shanghai Pudong International Airport on hand.Which accumulated a great number of China's top technologists in the liquid beverage industry.We have complete system from designing, manufacturing, installation, training to after service.Our main product water production line, carbonated beverage production line . Fruit juice and milk production line ,3 to 5 gallons production line, daily chemical production line and so on.Plat and tube UHT device, CIP system.All the products are sold well.We devote ourselves to the development, research and production of liquid food and beverage filling and packing industry .



Advantage

(1)A to Z turnkey plant provider
(2)Fully automatic or economic solution optional
(3)10+ years of global market experience
(4)Serve customers over 50 countries and regions worldwide

Stainless Steel 220V 10000bph Water Bottles Filling Machine 21

Stainless Steel 220V 10000bph Water Bottles Filling Machine 22

Q1: Proposal design and make budget
We are capable of providing specialized proposal design and make a general budget for you.
Q2: Equipment production&commissioning
We will arrange the production for you as soon as the order confirmed, and make sure the quality of products, We have client cases in different countries , we can provide theirproduction working video for you .
Q3: Factory layout design
Machines and factory layout design is also available after the proposal confirmed.
Q4: Bottle shape design
We can also help to do the bottle shape design for you according to your needs.
Q5: Label Design
We can also help to design the label for you, and you can share with us your idea too.
Q6: Raw Material supply
We are capable of provide one-stop service, so the raw material supply is also available.

Stainless Steel 220V 10000bph Water Bottles Filling Machine 23

<1>Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.

<2>Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

<3>Quality guarantee
We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.
