2000ml Automatic Soft Drink Filling Machine

2000ml Automatic Soft Drink Filling Machine

  • High Light

    2000ml Automatic Soft Drink Filling Machine

    ,

    8.3KW Automatic Soft Drink Filling Machine

    ,

    10000bph carbonated water making machine

  • Type
    Carbonated Soft Drink Beverage Filling Machine
  • Capacity
    10000-12000BPH
  • Automatic Grade
    Automatic
  • Size
    4550*2650 *2400MM
  • Weight
    8500KGS
  • Packaging Materia
    Glass,Plastic, Wood
  • Power
    8.3KW
  • Bottle Type
    Plastic Screw Cap
  • Operation
    Touch Screen ,Plc
  • Filling Material
    Beer, Milk, Water, Oil, Juice
  • Function
    Bottle Washing Filling Capping
  • Bottle Size
    200-2000ML
  • Packaging Type
    Barrel, Bottles, Cartons
  • Marketing Type
    New Product 2020
  • Certification
    CE, ISO 9001:2008
  • Condition
    New
  • Filling Type
    Under Pressure Filling
  • Workshop Layout
    Free Design
  • Driven Type
    Electric
  • Brand Name
    Bievo
  • Place of Origin
    China,Jiangsu
  • Brand Name
    BIEVO
  • Certification
    CE
  • Model Number
    CGFD40-40-10
  • Minimum Order Quantity
    1set
  • Price
    35000dollers/set
  • Packaging Details
    wood case
  • Delivery Time
    30 working days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10 sets per month

2000ml Automatic Soft Drink Filling Machine

Plastic Pet Bottle CSD Carbonated Soft Drink Beverage Filling Botling Machine/ Production Line

2000ml Automatic Soft Drink Filling Machine 0

Product Description:

Products Introduction Of Carbonated Soft Drink Beverage Filling Botling Machine

1. The Advanced Carbonated Beverage Filling Machine / Soda Water Filling Equipment is mainly used for filling soft drink. It combines washing and filling and capping as one automatic body suitable for PET or other plastic bottles. The equal pressure filling technology is adopted enabling it to fill more efficiently and more stably with more output than the machine of the same level from others.
2. Besides using photo-electronic detectors to detect the running of every important sub-process, it employs PLC from OMRON for automatic control of the whole process and new type air-channel for bottle-loading featuring speediness and damage-free of bottle.
3. The handing-over of bottles between two linking structures is fulfilled by applying clamping-bottle-neck method.
4. For bottle of different shape only a few parts need to be changed and the substituting is simple, which shows the machine is of good adaptability.
5. High automation and easy operation make it an ideal option for beverage companies.

Advantage:

A. High automation level, compact structure, attractive appearance, convenient and simple operation,

safe and reliable and adjustable continuous production capacity, low labor intensity.
B. The main machine adopts advanced PLC control technology
C. The key electric elements adopt products made by international famous companies, such as

Mitsubishi and Siemens.
These series carbonated drink filling machine can handle max 2 liter pet bottle. Welcome to inspect

Carbonated Drink Filling Machine in our factory.

Technical Parameters:

odel
CGFD8-8-3
CGFD12-12-6
CGFD18-18-6
CGFD 24-24-8
washing, filling and capping heads No.
2008/8/3
2012/12/6
18-18-6
24-24-8
Capacity
1500~2000BPH
3000~3500
4000~5000
6000~8000
Bottle Volume Range
volume=330-2000ml
φ=50-110 H=150~340mm volume=330-2500ml
Motor power(kw)
Main motor
Main motor 3.5kw
Main motor 4.0kw
Main motor 4.8kw
Overall dimensions (mm)
1.9kw
2450*1800*2400
2650*1900*2400
2900*2100 *2400
Weight (kg)
1900*1420*2000
2500
3500
4500
Model
CGFD 32-32-8
CGFD 40-40-10
CGFD 50-50-12
CGFD 60-60-15
washing, filling and capping heads No.
32-32-8
40-40-10
50-50-12
60-60-15
Capacity
8000-10000
10000-12000
12000-15000
15000-18000
Bottle Volume Range
volume=330-2000ml
φ=50-110 H=150 ~340mm volume=330-2500ml
Motor power(kw)
Main motor 7.6kw
Main motor 8.3kw
Main motor 9.6kw
Main motor 15Kw
Overall dimensions (mm)
4100*2000 *2400
4550*2650 *2400
5450*3210 *2400
5500*3510 *2400
Weight (kg)
6500
8500
9800
12000

Machines Details :

3 IN 1 Carbonated Soft Drinks Filling Machine

2000ml Automatic Soft Drink Filling Machine 1

2000ml Automatic Soft Drink Filling Machine 2

Out Look:

> 304 stainless steel frame
> Tempering Glass window, Clear & no odor
> Excellent start wheel design, easy change over parts
> Machine Base with anti-rust process, ensure the forever antirust
> All seal where liquid may Leakage & base neck come with rubber, water proof
> Manual lubrication system

Washing Part:

2000ml Automatic Soft Drink Filling Machine 3

➢ All 304 stainless steel rinser heads, water spray style inject design, more save water consumption & more clean
➢ 304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing
➢ 304 stainless steel washing pumps

Filling Part :
2000ml Automatic Soft Drink Filling Machine 4
➢ High precision filling nozzle, PLC variable signal control, ensure high filling precision & filling smoothly & steadily,
➢ All 304 stainless steel contact parts & liquid tank, fine polish, easy to clean
➢ No bottle no filling
Capping Part :
2000ml Automatic Soft Drink Filling Machine 5

➢ Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping
➢ All 304stainless steel construction
➢ No bottle no capping

Electrical Brand List
AC Contactor
SIEMENS (GERMANY)
Thermal overload relay
SIEMENS (GERMANY)
PLC
SIEMENS (GERMANY)
Touch Screen
SIEMENS (GERMANY)
Converter
SIEMENS (GERMANY)
Power Switch
SIEMENS (GERMANY)
Intermediate Relay


SCHNEIDER (FRANCE)

2000ml Automatic Soft Drink Filling Machine 6

2000ml Automatic Soft Drink Filling Machine 7

2000ml Automatic Soft Drink Filling Machine 8

Zhangjiagang City Bievo Machinery Co., Ltd. is located in a national level development zone - Zhangjiagang Economic And Technology Development Zone, covering area more than 8,000 square meters.We enjoy convenient transportation with Shanghai Hongqiao International Airport and Shanghai Pudong International Airport on hand.Which accumulated a great number of China's top technologists in the liquid beverage industry.We have complete system from designing, manufacturing, installation, training to after service.Our main product water production line, carbonated beverage production line . Fruit juice and milk production line ,3 to 5 gallons production line, daily chemical production line and so on.Plat and tube UHT device, CIP system.All the products are sold well.We devote ourselves to the development, research and production of liquid food and beverage filling and packing industry .

2000ml Automatic Soft Drink Filling Machine 9

2000ml Automatic Soft Drink Filling Machine 10

Q1: Where is your factory? How can I visit there?

A1: Our location is No.66, Baixiong Road, Sanxing Town, Zhangjiagang City, Jiangsu Province, China
Our factory is nearby from Shanghai City, if you fly from abroad, we can pick you up at the airport.

Q2: What's your payment stipulation?
A2: Our standard payment is 30% of the total amount for deposit, pay the balance before the shippment. For the others,
we can further discuss.

Q3: Do you have technicians for installation?
A3: We are responsible for the installaion in your country, you can also arange your staffs to our factory to learn how to operate the complete line.

Q4: How about the spare parts?
A4: We will send one year enough easy broken spare parts together with the machines when shipping, In the course of the warranty time, we can delivery you including the cost and fees.
2000ml Automatic Soft Drink Filling Machine 11

<1>Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.

<2>Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

<3>Quality guarantee
We promise that our goods are all new and not used. They're made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.
