2 Degree CE 2500ml Carbonated Soft Drink Filling Machine

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine

  • High Light

    BCG18-18-6 Carbonated Soft Drink Filling Machine

    ,

    2500ml Carbonated Soft Drink Filling Machine

    ,

    BCG18-18-6 small scale soda bottling equipment

  • Type
    Bottle Filling Machine
  • Name
    Glass Bottle Beer Filling Machine
  • Capacity
    2000BPH
  • Bottle Type
    Glass Bottle Crown Cap
  • Filling Material
    Beer Or Carbonatd Drinks
  • Bottle Size
    200-2500ml (Customized)
  • Machine Size
    3100*2300*2800mm
  • Weight
    4000KG
  • Filling Temperature
    2~4degree
  • Advantage
    High Effective
  • Machines Material
    Stainless Steel SUS 304/316L
  • Control
    SIEMENS
  • Electric Parts
    Schneider
  • Function
    Glass Bottle Beer Filling And Packing
  • Marketing Type
    Easy To Operate
  • Condition
    New
  • Filling Type
    Isobaric Filling
  • Washing Heads
    18Heads
  • Filling Heads
    18Heads
  • Capping Heads
    6Heads
  • Place of Origin
    China,Jiangsu
  • Brand Name
    BIEVO
  • Certification
    CE
  • Model Number
    BCG18-18-6
  • Minimum Order Quantity
    1set
  • Price
    26500dollers/set
  • Packaging Details
    wood case
  • Delivery Time
    30 working days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10 sets per month

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine

Professional Manufacture Small Automatic Glass Bottle Beer Filling Machine

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 0

Product Description:

Products Introduction Of Carbonated Soft Drink Beverage Filling Botling Machine

Glass bottle three-in-one filling unit. This machine is suitable for the filling and sealing of glass bottle crown cap, aluminum screw cap, triple screw cap or four screw cap container. It is suitable for various beverages such as beer, wine, etc, can be selected according to the actual requirements of the user atmospheric pressure filling valve or negative pressure filling valve or isostatic filling, the machine is a normal pressure liquid surface filling, liquid level Height adjustable.

Advantages:
1. This machine is suitable for high temperature filling or normal temperature filling or isostatic filling.
2. The bottom of the bottle lifting and lowering mechanism, with elastic pressure system, to protect the bottle mouth sealed canned.
3. Filling tank liquid level automatic control system.
4. Magnetic type cover cover technology, no friction damage, set cover warehouse and cover in one.
5. Grasping and capping technology, accurate and reliable, in the case of matching the bottle mouth and the cover, the pass rte is as high as 98%.
6. Magnetic torque decoupling mechanism, never wear.
7. Synchronous belt holding device ensures that the bottle does not rotate when the cap is screwed.

Technical Parameters Of Carbonated Soda Water Filling Machine :

Model (BCGF)
24/24/6
32/32/8
40/40/12
Washing heads
24
32
40
Filling heads
24
32
40
Capping heads
6
8
12
Capacity (BPH)
5000
8000
12000
Power(kw)
4.5
6
7.5
Dimension (mm)
3100*2300
3800*2500
4600*2800
*2800 *2900 *2900
Weight(kg)
4500
5600
8500

Machines Details :

3 IN 1 Carbonated Soft Drinks Filling Machine



2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 1

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 2

Out Look:

> 304 stainless steel frame
> Tempering Glass window, Clear & no odor
> Excellent start wheel design, easy change over parts
> Machine Base with anti-rust process, ensure the forever antirust
> All seal where liquid may Leakage & base neck come with rubber, water proof
> Manual lubrication system

Washing Part:

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 3

- Into bottle way is air conveyor direct connection with bottle dial.
- All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean.
- 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.

Filling Part :
2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 4

The three-in-one unit completes the three processes of bottle washing, filling and capping at one time, with little bottle wear, accurate and stable transmission, and convenient bottle type replacement. * The specially designed all-stainless steel bottle washer bottle clamp is sturdy and durable, and does not touch the threaded part of the bottle mouth to avoid secondary pollution of the bottle mouth. * High-speed and large-flow gravity filling valve, fast filling speed, accurate liquid level without liquid loss.

Capping Part :
2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 5

* All parts in contact with liquid are made of high-quality stainless steel materials or food-grade engineering plastics, which meet the national food hygiene standards. * The bottle bottom support plate of the bottle output wheel adopts a spiral descending method, and the height of the bottle conveyor chain is not required to change the bottle shape.

Technical Partment Of Carbonated Soda Water Filling Machine
S/N
Name
Brand
Country
1
Main motor
ABB
Switzerland
2
Inverter
MITSUBISHI
Japan
3
PLC
OMRON
Japan
4
Touch screen
MITSUBISHI
Japan
5
Contactor
SCHNEIDER
France
6
Thermo- relay
SCHNEIDER
France
7
Air-break switch
SCHNEIDER
France
8
Proximity switch
TURCK
USA
9
Photoelectric switch
BANNER
USA
10
Air circuit system
SMC
Japan
11
Water pump
Southern
China

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 6

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 7

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 8

Zhangjiagang City Bievo Machinery Co., Ltd. is located in a national level development zone - Zhangjiagang Economic And Technology Development Zone, covering area more than 8,000 square meters.We enjoy convenient transportation with Shanghai Hongqiao International Airport and Shanghai Pudong International Airport on hand.Which accumulated a great number of China's top technologists in the liquid beverage industry.We have complete system from designing, manufacturing, installation, training to after service.Our main product water production line, carbonated beverage production line . Fruit juice and milk production line ,3 to 5 gallons production line, daily chemical production line and so on.Plat and tube UHT device, CIP system.All the products are sold well.We devote ourselves to the development, research and production of liquid food and beverage filling and packing industry .

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 9

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 10

1.Can your factory provide he whole plant from A to Z?
Yes, we can provide the complete plant, from bottling making plant,water purification plant,to filling packing plant.

2.Are all machinery your factory made?
Our factory make the water purification and filling packing plants.we do not make the bottle making machinery,we have good quality bottle making machinery partner,and we provide to customer same long warranty time and good after service.

3.How can I know the machinery quality before i order?
First,we will invite you visiting our factory to check the machines quality,and show the machines running for you in our factory.

4.What certificates you can provide?
Our factory provide the CE,SGS,ISO,and according to some countries,we also can provide the PVOC, COC,SONCAP...etc.

2 Degree CE 2500ml Carbonated Soft Drink Filling Machine 11

What kind of service can your company provide?
A: Throughout the cooperation process, our company can provide the following three services.
1.Sample service
We can send you a video of the work of this machine.
You are very welcome to visit our company and check the operation of the machine on site. We will send someone to pick you up at the airport.
2. Customized service
We can customize the machine according to the customer's requirements (such as material, power, filling type, bottle size, etc.), and our engineers will also provide professional advice to help customers better establish the ideal factory.
3. After sales service
After receiving the final payment, we will provide the bill of lading in time to ensure that the customer receives the goods as soon as possible.
Once you have completed all the preparations, we will send engineers to your factory to install the machines and train your staff for free until they are able to operate the machine well.
We can provide one year warranty and spare parts, and free lifetime technical service.
