Product Details:

Place of Origin: China,Jiangsu
Brand Name: BIEVO
Model Number: DGF12-1

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: 20000dollers/set
Packaging Details: wood case
Delivery Time: 20-30working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 sets per month
Get Best Price Contact Now

Detail Information

Certification: CE, ISO 9001:2008 Type: Can Beverage Filling Machine
Automatic Grade: Automatic Material: SUS 304
Voltage: Customized Dimension(L*W*H): 2200X2100X2200MM
Weight: 2500KG Filling Material: Carbonated Drinks
Filling Valve Head: 12 Can Shape: Aluminum Can
Core Components: Pump, PLC Filling Accuracy: 99.9%
Condition: New Key Selling Points: Full Automatic
Bottle Size: 200ml-1500ml (Customized) Function: Cans Filling Sealing Machine
Control System: PLC+Touch Screen Workshop Layout: Free Design
Application: Beverage Packaging Material: Wood
Driven Type: Electric Machinery Capacity: 6000cph
High Light:

330ml Can Beverage Filling Machine

,

550ml Can Beverage Filling Machine

,

6000bph water can filling machine

Product Description

6000BPH Aluminum Cans Filling Line/Beer Can Filling Line Machine For 330ml 550ml

Canned beverage machines are used to fill liquid in cans and seal cans.

The Liquid can filling, sealing machines were made based on absorbing advance technology from abroad. All the canning machines adopt the advanced mechanical, electrical and pneumatic control technology. Can filling and seaming system were made in one unit. The filling system driving force was supplied by seaming system to assure the synchronization. With using counter pressure filling principle, filling work is stable, fast, accurate and has no leakage. Capping performance is well. The can filling machine owns stable working, elegant appearance, easy maintainence, motor speed frequency control. It also can be equipped with long-range control system according to customers’ requirement. It is the ideal machine for beer and beverage factory.

We are specialized in manufacturig can filling machine from China.

Machine include function : Filling Capping
Application: Beverage, water , cola , beer , juice , oil

Usage: The machine is used in washing can, filling carbonated drinks in beer and coca cola , pepsi drink and other carbonated drink production industry and capping.

Aluminum Cans Filling Line/Beer Can Filling Line Machine For 330ml 550ml

1, Automatic control by PLC,could be adjustable when the machine is open.

2, Cleaning and filling could be finished in this machine at one-time.

3, Pipeline use steel edge which could ensure no-leaking and long life

4,Well- used for beer fresh bucket and draught beer bucket

5, Has CO2 prepairation function

6, All use Pneumatic double acting Angle seat valve which could ensure the action sensitivity and reliability

7, Anoxic and rated pressure filling function

8, CIP automatic cleaning system

It is the preferred equipment for the medium beer and beverage plant.
We provide the complete pop cans / tin can filling and package solution ,from can depalletizer ,can rinsing machine ,can filling&sealing monoblock machine ,leakage check,liquid nitrogen dosing machine ,pasteurizer tunnel ,blow dryer ,carton package ,film package system ,which is widely used for the beverage ,beer ,juice industry and so on

Technical Specification
Model GF12-1 GF18-4 GF24-6
Capacity 1200-1500cans/hour 5000-6000 CPH 7000-9000 CPH
Can volume 200ml-1000ml 200ml-1000ml 200ml-1000ml
Can diameater 50-70mm 50-70mm 50-70mm
Bottle high 120-170mm 120-170mm 120-170mm
Machine power 1.5KW 2.2KW 3.7KW
Machine size 175x120x195CM 305x175x220CM 340X195X220CM

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 0

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 1



DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 2

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 3

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 4

S/N Name Brand Country
1 Main motor ABB Switzerland
2 Inverter MITSUBISHI Japan
3 PLC OMRON Japan
4 Touch screen MITSUBISHI Japan
5 Contactor SCHNEIDER France
6 Thermo- relay SCHNEIDER France
7 Air-break switch SCHNEIDER France
8 Proximity switch TURCK USA
9 Photoelectric switch BANNER USA
10 Air circuit system SMC Japan
11 Water pump Southern Japan















DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 5

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 6

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 7

Zhangjiagang City Bievo Machinery Co., Ltd. is located in a national level development zone - Zhangjiagang Economic And Technology Development Zone, covering area more than 8,000 square meters.We enjoy convenient transportation with Shanghai Hongqiao International Airport and Shanghai Pudong International Airport on hand.Which accumulated a great number of China's top technologists in the liquid beverage industry.We have complete system from designing, manufacturing, installation, training to after service.Our main product water production line, carbonated beverage production line . Fruit juice and milk production line ,3 to 5 gallons production line, daily chemical production line and so on.Plat and tube UHT device, CIP system.All the products are sold well.We devote ourselves to the development, research and production of liquid food and beverage filling and packing industry .

DGF12-1 330ml 550ml Can Beverage Filling Machine 6000bph Water Can Filling 8

Q: This is the first time I cooperate with your factory. How can I trust you about the machien quality?
A: Before ordering the machine, we will make the offer very clear. For example, the material thickness, the brand etc. We can have the video call and I will show what we have in the factory;
Also you can visit us to see the machine;


Q: If the quality doesn't meet my requirment, how can you solve this problem?
A: Before ordering the machine, we will negotiate the machine inspection standard. Then start production; If you are not satisfied with the quality, show us, we will re-do it before shipping;

Q: Can I run the machines in your factory if I buy the complete line in your factory?
A: Sure, why not. We will have the line connected and tested in our factory before shipping even you didn't mention; We will make it working before arriving at your factory;

Q: How can I get the machine?
A: Our company have the export license, so we can help to ship the machine to discharge port that you are available.

Q: How can I install the machine and commissioning? Do you have the technician to my factory?
A: We have the technician available to your factory for machine installation and commissioning; BUT client should be responsible for the round-way flight tickets, technicians' daily salary, local transportation, local hotel and eating.
