200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can

200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can

  • High Light

    200ml Soda Can Filling Machine

    ,

    1500ml Soda Can Filling Machine

    ,

    0.75KW soda can sealing machine

  • Type
    Can Beverage Filling Machine
  • Automatic Grade
    Automatic
  • Material
    SUS 304
  • Voltage
    Customized
  • Dimension(L*W*H)
    2200X2100X2200MM
  • Weight
    2500KG
  • Filling Material
    Carbonated Drinks
  • Filling Valve Head
    12
  • Can Shape
    Aluminum Can
  • Core Components
    Pump, PLC
  • Filling Accuracy
    99.9%
  • Certification
    CE, ISO 9001:2008
  • Condition
    New
  • Key Selling Points
    Full Automatic
  • Bottle Size
    200ml-1500ml (Customized)
  • Function
    Cans Filling Sealing Machine
  • Control System
    PLC+Touch Screen
  • Workshop Layout
    Free Design
  • Application
    Beverage
  • Packaging Material
    Wood
  • Driven Type
    Electric
  • Machinery Capacity
    6000cph
  • Place of Origin
    China,Jiangsu
  • Brand Name
    BIEVO
  • Certification
    CE
  • Model Number
    DGF12-1
  • Minimum Order Quantity
    1set
  • Price
    20000dollers/set
  • Packaging Details
    wood case
  • Delivery Time
    20-30working days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10 sets per month

200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can

Aluminum Soda Water Cans Filling Line Machine / Soda Can Filling Sealing Machine

Machine description :

It is applicable for equal pressure can filling sealing machine for carbonated drinks in beer and drink industry. It is a pop canned beer in the digestion and absorption of advanced foreign and domestic sealing machine on the basis of independent development of the can filling, sealing unit. Filling and sealing is the overall designed, power system by filling sealing system to ensure that both the absolute synchronization and coordination. It adopts the advanced machine, electrical equipment, and pneumatic control technology. It has the characteristics of filling reposefully, high speed, liquid level control, capping reliably, frequency conversion timing, less material loss. It can equip long-distance control system according to the customers’ request. It is the preferred equipment for the medium beer and beverage plant.

1. Filling and sealing is the overall designed, power system by filling sealing system to ensure that both the absolute synchronization and coordination.

2. It adopts the advanced machine, electrical equipment, and pneumatic control technology.

3. The requirements of the can filling machine
It is suitable for filling and sealing aluminum canned beer and carbonated soft drinks. It is equipped the advanced device,
electrical equipment, and pneumatic control technology. It has the characteristics of filling repose fully, high speed, liquid
level control, capping reliably, frequency conversion timing, less material loss. It can be equipped long-distance control system.
It is the preferred equipment for the medium beer and beverage plant.
We provide the complete pop cans / tin can filling and package solution ,from can depalletizer ,can rinsing machine ,can filling&sealing monoblock machine ,leakage check,liquid nitrogen dosing machine ,pasteurizer tunnel ,blow dryer ,carton package ,film package system ,which is widely used for the beverage ,beer ,juice industry and so on.

The machine is advanced filling and capping equipment, it’s designed on the basis of absorbing domestic and foreign advanced technology. It is mainly used in filling and capping carbonated beverages like soft drinks, cola, sparkling wine, etc. It has such advantages as advanced construction, stable working, convenient operation, and repair & maintenance, transducer control as well as high production efficiency. It is the ideal equipment for mid-scale & small-scale beverage factory.
Model
GDF 12-1
GDF 18-6
GDF 24-6
Production Capacity ( c/h)
1000-2000
3000-6000
4000-9000
Power ( kw )
0.75
3.7
3.7
Weight ( kg )
1800
2500
3000
Overall Dimensions ( mm )
1750*1140*1950
2320*1400*1900
2580*1675*1900

200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can 0

200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can 1



200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can 2

200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can 3

200-1500ml Soda Can Filling Machine 0.75KW Sealing For Aluminum Can 4

S/N Name Brand Country
1 Main motor ABB Switzerland
2 Inverter MITSUBISHI Japan
3 PLC OMRON Japan
4 Touch screen MITSUBISHI Japan
5 Contactor SCHNEIDER France
6 Thermo- relay SCHNEIDER France
7 Air-break switch SCHNEIDER France
8 Proximity switch TURCK USA
9 Photoelectric switch BANNER USA
10 Air circuit system SMC Japan
11 Water pump Southern Japan
